Wholesale carrier telecommunication services

MAXIMUM EFFICIENCY for best economical value

Smart and easy solution for backbone data transfer, site to site interconnection or last mile via Ethernet Transport (L2) service. This service is used by carriers and Internet Service Providers. Provides best value for money.

Benefits for you

• Fast and secure data transfer with minimal latency
• Last mile via fibre or microwave link in licensed and free band directly to end customer premises
• The service is provided using the Vodafone Business MPLS backbone network
• Possible upgrade to MEF CE 2.0 certified Carrier Ethernet
• Full VLAN transparency and L2 protocol tunnelling

Technical parameters

• Transport via Ethernet (L2) through Vodafone optical backbone network
• Dedicated full-duplex capacity: from 2 Mbps to 10 Gbps
• Transmission Interface: 100 Base-TX, 1000Base-T, 1000Base-LX, 10GBase-LX, 10GBase-ER, 10GBase-ZR
• Management of network layer protocols fully in the customer's control
• Fast response to capacity increases without the need for technology modifications for 2Mbps - 500Mbps capacities
• Service availability across Vodafone network
• Statistics on service operation, forwarding interfaces and their settings available via customer web portal
• High availability of services ensured by network topology and quality of active elements

All product sheets, contracts and other documentation can be found here.

ADVANCED AND INDEPENDENT INTERNET CONNECTION

The age of the dark fibres is gone. WDM service is DF state of art substitute and ideal solution for implementing backbone routes and connecting to peering centres. It is ideal Service Providers and carriers looking for high bandwidth. The comfort of the service is secured by guaranteed availability and advanced technological solution with emphasis on quality.

Benefits for you

• Full replacement for optical fibre
• Absolute independence from the transmitted protocol
• SLA for above standard requirements
• Delivered on Vodafone's robust fibre network
• Option to transmit the service via optical fibre directly at the customer's location

Technical parameters

• Transparent optical channel implemented at different wavelengths, transmitted in parallel over an optical fibre
• Capacities: 10 Gbps, 100Gbps
• Transmission Interface: 10GBase-LX, 100GBase-LR4
• Maximum availability of service determined by the principle of technology

All product sheets, contracts and other documentation can be found here.

Certified Carrier Ethernet from Vodafone

THE ONLY ETHERNET THAT WON'T LIMIT YOU IN ANY WAY

MEF standardized service for all international businesses that need to connect their offices with a high quality Ethernet across Europe. Next-generation data connectivity with variable feature settings based on ports, VLANs and classes of service.

Benefits for you

• Service availability guarantee for the entire solution (end-to-end)
• The line is completely separated from the public Internet, traffic cannot be monitored and is secure against attacks
• more than 250,000 access points and 100 data centres within reach of our worldwide network

Technical parameters

• Transport implemented on the Vodafone optical network
• Dedicated full-duplex capacity: from 2 Mbps to 10 Gbps
• Transmission Interface: 1000 Base LX, 10GBase-LR, 10GBase-ER, 10GBase-ZR
• The service runs on the Ciena equipment
• Comprehensive management services
• L2CP protocol tunnelling
• Traffic statistics through the online interface, including client port settings
• Line capacity is fully symmetrical and guaranteed
• SLA guarantee

All product sheets, contracts and other documentation can be found here.

TV THROUGH THE EYES OF PROFESSIONALS

Vodafone offers a technical solution, a service, to all producers, TV content providers, broadcasters, and TV content producers through "Technical Stream" product. Vodafone is the first provider in the Czech Republic which offers Technical Stream with the option of HD quality transmission on selected TV channels.

Technical parameters

All product sheets, contracts and other documentation can be found here.

INTERNET CONNECTION FOR YOUR CLIENTS

IP connectivity from Vodafone, thanks to broad local access infrastructure, provide your clients with better quality and more affordable connection to the Internet. Internet connectivity service is designed for all Internet Service Providers, cable TV operators or civil associations (freenet).

Benefits for you

• Detailed statistics on the operation of the service are available via customer web portal
• Optional dynamic routing - BGP protocol, both in private and public version
• IPv4 and IPv6 addresses available
• High service reliability thanks to redundant backbone network topology
• Last mile provided via fibre or microwave link in licensed and free bandwidth directly to end customer premises
• Microwave link housing and technology at Vodafone site

Technical parameters

• Peering connections all major European public peers
• variety of local and international private peers with all important players
• Backbone connectivity provided via Vodafone international network
• The backbone part of the network (Core) is connected between the main nodes with 100 Gbps capacities with MPLS support at the level of active elements, the access part of the network is implemented by GE with n* Gbps and 10 Gbps capacities
• Dedicated full-duplex capacity: from 2 Mbps to 100 Gbps
• Transmission Interface: 1000Base-T, 1000Base-LX, 10GBase-LX, 10GBase-ER, 10GBase-ZR, 100GBase-LR4

All product sheets, contracts and other documentation can be found here.

Vodafone Peering is the direct interconnection of two peer ASNs, it is set up to exchange direct traffic between these ASNs for the purpose of technically and operationally efficient handling of this traffic. A Private Network Interconnection (PNI) is established to connect these two ASNs. Physically, it is a service interconnection at Layer 1 or Layer 2 of the OSI model. The volume of traffic that is exchanged via the PNI between the Vodafone network and the Partner's network is measured on an ingress and egress basis using the 95th percentile method. This means that every 5 minutes the value of the exchanged traffic is subtracted on the inbound and outbound direction. At the end of the measured settlement period, which shall be one calendar month unless otherwise agreed by the Parties, the top 5% of these readings shall be discarded and the highest remaining value for each direction of traffic shall be taken for settlement purposes.

Peering for the purpose of this Agreement is defined as the interconnection of two peer-to-peer autonomous Internet networks. Therefore, if there is a significant difference between the traffic exchanged between the networks in the inbound and outbound directions above the ratio set forth below, the party whose network received traffic more than that ratio shall have the right to charge the other party for such excess data. The Party that sent the traffic to the other Party's network shall be obliged to pay this fee. The evaluation of the traffic shall be carried out at the end of each calendar month.

Peering policy of Vodafone Czech Republic, a.s.
Basic parameters of the peering policy of Vodafone Czech Republic, a.s.:

• Vodafone peers with local AS, for international AS we can mediate
• the peering connection is codified in writing in a Peering Agreement between Vodafone and the Customer,
• peering is for AS with which we exchange at least 3 Gb of traffic during peak hours,
• measurement of traffic interchange is performed using the 95% percentile method,
• each party bears its own costs for the operation of the interconnection of the two ASNs, in the case of a common cost, the parties agree to cover this cost
• The traffic on the PNI is balanced, If the ratio of IN and OUT traffic is unbalanced, and above a ratio of 1:3, or any other ratio agreed by the parties, the network that sent more traffic to the other network is liable to pay for the excess data. The details are addressed in the relevant Peering Agreement,
• Vodafone reserves the right to create a PNI with another AS even if one or more of the conditions mentioned above are not met if it makes economic or operational sense for Vodafone to do so.

All product sheets, contracts and other documentation can be found here.

SECURITY FOR YOUR BUSINESS

Vodafone Anti-DDoS service provides effective protection against majority of known DDoS attacks, security and protection of the network and applications running on it. The service is designed for anyone whose services are inextricably linked to a functioning internet connectivity. These are mainly ISPs, financial institutions, e-shops, etc. Due to the ease of creating an attack, their frequency increases and the field of potential targets expands, which is why your company may find itself under a DDoS attack.

Reduce the risk of unexpected costs and operational expenses. Size doesn't matter - no business is so small that it can't be the target of a DDoS attack

Benefits for you

• Very fast reaction to attack - within 180 seconds
• Even in a defensive response to an attack, data does not leave the Vodafone network
• Filtration delay up to 100ms
• The service is fully managed and works automatically
• No need for changes to your network topology
• Possibility of individual setting of traffic evaluation
• We will also connect customers with their own AS to the service

Technical parameters

• Response time in case of attack less than 60 seconds.
• Guaranteed annual service availability (Arbor Platform) 99,9 %
• Impact on latency, jitter, and packet loss in the Internet service during traffic clean-up. When an attack occurs, traffic is routed through the clean-up center - impact on response time in the case of mitigation: < 3 to 6ms.
• Minimum transfer rate for cleaning 100 Mbps
• Maximum time to clear traffic after a DDoS attack 5 minutes
• Maximum operational capacity of scrubbing center 3x80Gbps= 240Gbps
• Reporting YES

DDoS attack

A DDoS attack is a technique of overloading the network or server resources of a service provider or individual customers by making their service unavailable on the Internet. DDoS attacks can be conducted volumetrically (overwhelming the ability of a processor or memory to respond to many false requests) or exploit weaknesses in IP protocols or misconfigured devices to trigger a DDoS attack. DDoS renders the attacked service unavailable, and in many cases, data loss is reported in an attack on enterprise infrastructure.

Other benefits

• It can quickly and accurately distinguish between different categories of behaviour: legitimate (normal) traffic, malicious (offensive) traffic and unusual traffic resulting from normal traffic.
• For protection to be truly effective and to be of real benefit to the customer, protection can be defined exactly according to the needs of the customer and their server/service.
• Anti-DDoS does not replace the firewall, does not address misconfigured devices or applications, or points with weak passwords! Based on analysis, the service detects general signs of an attack and removes them from the data stream, significantly reducing the risk of a breach or overwhelming the protection with malicious traffic.

All product sheets, contracts and other documentation can be found here.

ENTRUST THE CARE OF YOUR COMPANY EQUIPMENT TO OUR HANDS

With Vodafone Housing, your worries become our responsibility. The service is dedicated to all operators and Internet Service Providers with access to all Vodafone wholesale services who are looking for responsible administrators for their corporate server infrastructure. Our secure datacentres equipped with professional technologies will take care of your company server. Its connection to the backbone network ensures smooth and error-free operation of critical applications.

Benefits for you

• Availability of services
• Flexibility
• Reducing the burden on in-house IT
• Positive financial impact

Technical parameters

• Total number of positions per rack up to 42 U
• Maximum power consumption per rack up to 7.1 kW
• Each rack has its own temperature sensor
• Controlled temperature (22+-2 °C) and relative humidity (60-80 %)
• Fire detection and automatic fire extinguishing system
• Liquid leak detection and circuit closure system
• Two independent power circuits to each rack
• UPS and backup diesel generators (N+1)

Other benefits

Data centre connectivity

• Connection to the Vodafone backbone network
• Fully redundant DWDM network and backup internet connection
• Dedicated connectivity, data transfer volume is not limited in any way
• Support IPv4, IPv6

Security

• Lockable space
• Security and safety service 24×7
• Camera system and monitoring
• Electronic access system to data centre premises
• Location of the site (non-floodplain, unexposed site)

Technical support

• 24×7 surveillance
• Installation support

All product sheets, contracts and other documentation can be found here.

Renting a fully managed endpoint device (router or switch) is an innovative solution for providing network connectivity for your organization without the need to manage and maintain your own equipment. For this service we use CIENA and CISCO equipment according to your requirements.

View all product data sheets, contracts and other documentation.

Reference offer for access to LTE network operating on 800/1800/2600 MHz frequencies.

Reference offer for international roaming.
